Yongte PE-RT floor heating pipe equipment is a professional device specializing in the manufacture of floor heating tubes. It consists of feeding, extrusion, sizing cooling, traction cutting and other systems. The raw materials are molded by precise temperature and pressure control. Its simple operation, high degree of automation, can efficiently produce accurate size, excellent performance of the heating pipe, to meet the needs of floor heating.
PE-RT floor heating pipe equipment is specially used for the manufacture of PE-RT floor heating pipe specialized equipment. The equipment has an irreplaceable important position in the whole production process. Its performance and quality have a critical impact on the successful production of floor heating tubes with efficient heat transfer performance and durable characteristics. The equipment with excellent performance can accurately control the production parameters, ensure that the raw materials are fully plasticized and heated evenly, so that the produced pipe structure is stable and the performance is excellent, and provide high-quality products for the market.
The raw material of yongte PE-RT floor heating tube is fed into the extruder by the feeding system, and extruded after being heated and plasticized by screw rotation. head mold gives the pipe shape, the sizing cooling system makes it finalize, the traction system pulls at a constant speed, and the cutting machine cuts according to the set length. All systems work together to produce high-quality PE-RT floor heating tubes.
1. Feeding system: Automatic feeding device is generally used, which can accurately and stably transport PE-RT raw material particles to the extruder, reduce manual operation and improve feeding efficiency.
2. Extruder: As one of the core components, the quality of the extruder directly affects the production efficiency and quality of the pipe. Through heating and rotation of the screw, the raw material is molded into a uniform melt and extruded at a certain pressure and speed.
The screw design is unique, which can achieve good plasticizing effect and stable extrusion volume.
Equipped with accurate temperature control system, independent temperature control for different areas to ensure that raw materials are processed at the appropriate temperature.
3. Head mold: determines the shape, size and wall thickness of the pipe. High quality head dies produce tubes with precise dimensions and smooth inner walls.
4. Sizing cooling system: including vacuum sizing device and cooling sink. Vacuum sizing ensures the accuracy of the outer diameter of the pipe, and the cooling water tank quickly reduces the temperature of the pipe by circulating water, so that it can be solidified.
5. Traction system: provides stable traction force, so that the pipe moves forward at a constant speed, to ensure the continuity of production and the consistency of the pipe length.
6. Cutting system: precisely cut the pipe according to the preset length to ensure that the length of each pipe meets the requirements.
7. Control system: Advanced PLC control system is adopted to realize automatic control and monitoring of the entire production process. Operators can easily set production parameters through the touch screen, real-time monitoring of equipment operating status and production data.
1. High production efficiency: continuous production can be achieved, which greatly improves the output of pipes.
2. Good product quality: strictly control the dimensional accuracy, mechanical properties and temperature resistance of the pipe to ensure that the product meets the relevant standards and customer requirements.
3. Easy operation: high degree of automation, the operator can skillfully operate the equipment after simple training.
4. Strong adaptability: According to different pipe diameter and wall thickness requirements, replace the mold and adjust the production parameters to meet the diversified market demand.
PE-RT floor heating tubes are a premium choice in the field of floor heating.
It is made of heat-resistant polyethylene (PE-RT) material. This material gives the heating tube excellent temperature resistance, can work stably in a wide temperature range, and is not easy to deform for long-term use.
It is extremely flexible and can be easily bent and laid to adapt to different room layouts and installation needs. Moreover, the thermal conductivity efficiency is high, and the heat can be quickly and evenly transferred to improve the heating effect.
PE-RT floor heating pipe also has good compression and aging resistance, long service life. Widely used in home, office and other places, to create a warm and comfortable environment for users, is an efficient, durable and economic heating solution.
